Champ MLLA Hazardous Area Linear LED Light Fixtures UL长条型防爆灯

品牌： EATON CROUSE-HINDS
型号: MLLA4 MLLA2 MLLAN2 MLLAN4 MLLAW2 MLLAW4
产品说明: Eaton Crouse-Hinds series Champ MLLA Hazardous Area Linear LED Light Fixtures
The Crouse-Hinds series Champ MLLA linear LED is specifically designed to replace fluorescent T12, T8 and T5HO lighting in harsh and hazardous applications. Available in 2 foot and 4 foot versions with 4,000 lumens and 8,000 lumens respectively, the Champ MLLA features a rugged and durable design with the industry’s most versatile and flexible mounting options.
The Champ MLLA is the ideal solution for high vibration, impact and hose down applications in Class I and Class II hazardous locations.
The MLLA is also is available with a self-contained battery system for emergency lighting applications.
Kunshan Beiyuan Electric Co.,Ltd - Eaton Crouse-Hinds Series Authorized Distributor

分享到:

立即咨询

产品详情
产品手册

Eaton Crouse-Hinds series Champ MLLA Hazardous Area Linear LED Light Fixtures
Certifications:
NEC/CEC:
Class I, Division 2, Groups A, B, C, D
Class I, Zone 2
Class II, Division 1, Groups E, F, G
Class III
Type 4X, IP66/IP67
Marine and wet locations
UL standards:
UL844 – Electrical Fixture Hangers for Hazardous Locations
UL924 – Emergency Lighting Equipment (emergency battery back-up model)
UL1598 – Luminaire
UL1598A – Luminaire for Installation on Marine Vessels
UL8750 – Standard for Light Emitting Diode (LED) Equipment for use in Lighting Products
CSA standard:
C22.2 Nos. 137, 141, 250
Standard materials
Housing – copper-free aluminum; Corro-free epoxy powder coat (optional)
Lens – glass; polycarbonate, diffused glass or diffused polycarbonate (optional)
EATON/CROUSE-HINDS/COOPER/CEAG/MEDC-一级代理-工厂直发-昆山倍源电气有限公司
EATON伊顿产品涵盖：德国CEAG防爆，美国CROUSE-HINDS防爆，COOPER库柏防爆
MEDC防爆声光报警,CAPRI防爆电缆戈兰,RAXTON防爆电气管件,REDAPT防爆电气管件
经销：APPLETON,KILLARK,BARTEC,R.STAHL,RITTAL,HAWKE,CMP,CCG CABLE GLAND
订货号 Order No.:

MLLA2N-UNV34-S891-M2

MLLA2N-UNV1-S903D-P-M2

MLLA2-UNV1-S903D-P-M2

MLLA4N-UNV1-S891-M2

MLLA4N-UNV34-S891-M2

MLLA4N-UNV1-M2

MLLA2-UNV1-P-M2

MLLAW2-UNV1-M2

MLLA2-UNV1-S891-P-M2

MLLA2-UNV34-S891-M2

MLLA4-UNV1-S903D-P-M2

MLLAW4-UNV1-M2

MLLA2N-UNV34-S903-P-M2

MLLA2-UNV34-S903D-P-M2

MLLA4N-UNV1-S903D-M2

MLLA4-UNV1-S891-M2

MLLA4N-UNV1-S903-M2

MLLA4-UNV34-S903-M2

MLLA4-UNV1-M2

MLLA2N-UNV1-P-M2

MLLA2N-UNV1-S903-P-M2

MLLA4N-UNV34-P-M2

MLLAW4N-UNV1-M2

MLLA2-UNV1-M2

MLLA2-UNV34-S903D-M2

MLLA4-UNV1-S903-M2

MLLAW4-UNV1-S903-M2

MLLA4-UNV34-S903D-P-M2

MLLA4-EM1-DRIVER KIT

MLLA2-UNV1-DRIVER-KIT

MLLA4-UNV1-S891

MLLA4-UNV1-DRIVER-KIT

MLLA2N-UNV1-S903D-M2

MLLA2N-UNV34-P-M2

MLLA4N-UNV1-S891-P-M2

MLLA4N-UNV1-S903-P-M2

MLLA4N-UNV34-S903D-M2

MLLA4-UNV34-S891-M2

MLLA4-UNV34-S903-P-M2

MLLA2N-UNV34-S903D-P-M2

MLLA4-UNV34-P-M2

MLLA2-UNV1-S903-M2

MLLA2N-UNV34-S903-M2

MLLA4-UNV1-S891-P-M2

MLLAW4N-UNV1-S903-P-M2

MLLAN2-UNV1-W-M2

MLLAN4N-UNV1-P-M2

MLLAN4N-UNV34-S903D-P-M2

MLLAN4-UNV1-S903-M2

MLLAW2N-UNV1-M2

MLLAW2N-UNV34-S903D-M2

MLLAW2-UNV1-W-M2

MLLAW4N-UNV1-S903D-M2

MLLAW4-UNV1-S903-WH-M2

MLLA2N-UNV1-S891-W-M2

MLLA2-UNV1-S903-WH-M2

MLLA4NCW-UNV1-S903D-M2

MLLAN2N-UNV1-S891-M2

MLLAN2N-UNV34-S903D-P-M2

MLLAN2-UNV1-S903-P-M2

MLLAN4NCS-UNV1-S903-1R-WH-M2

MLLAN4N-UNV34-S891-W-M2

MLLAN4-UNV1-S903D-P-M2

MLLAN4-UNV34-S903-W-M2

MLLAW2N-UNV34-S891-P-M2

MLLAW2-UNV1-S903-P-M2

MLLAW4N-UNV1-S891-P-M2

MLLAW4N-UNV34-S903D-P-M2

MLLAW4-UNV1-S903-SRG1-EM1-M2

MLLA2N-UNV34-S891-P-M2

MLLA2-UNV34-S903D-W-M2

MLLA4N-UNV1-SRG1-EM1-M2

MLLAW2-UNV1-S903D-M2

MLLAW2-UNV34-S903-W-M2

MLLAW4N-UNV34-S891-P-M2

MLLAW4-UNV1-S903D-P-M2

MLLAW4-UNV34-S903-P-M2

M2-MLLA4-UNV34-DRIVER-KIT

MLLA4N-UNV34-S903-W-M2

MLLAN2N-UNV34-P-M2

MLLAN2-UNV1-P-M2

MLLAN2-UNV1-S891-W-M2

MLLAN2-UNV34-S903D-M2

MLLAN2-UNV34-S903-M2

MLLAN4N-UNV1-S903D-W-M2

MLLAN4N-UNV1-S903-W-M2

MLLAN4N-UNV34-W-M2

MLLAN4-UNV1-S891-M2

MLLAN4-UNV34-S891-M2

MLLAN4-UNV34-S903D-M2

MLLAW2N-UNV1-S903D-P-M2

MLLAW2N-UNV1-S903-W-M2

MLLAW2-UNV1-S891-P-M2

MLLAW2-UNV34-S903-M2

MLLAW4N-UNV34-S891-M2

MLLAW4N-UNV34-S903D-W-M2

MLLAW4-UNV1-S903D-EM1-M2

MLLAW4-UNV34-S903D-W-M2

MLLA2-UNV34-M2

M2-MLLA2-UNV34-DRIVER-KIT

M2-MLLA4-UNV1-DRIVER-KIT

MLLA2N-UNV1-S903-WH-M2

MLLA2N-UNV1-SRG1-EM1-M2

MLLA2N-UNV34-W-M2

MLLA2-UNV1-S891-WH-M2

MLLA2-UNV34-S891-P-M2

MLLA4CW-UNV1-S903D-1R-P-M2

MLLA4N-UNV1-S903D-WH-M2

MLLA4N-UNV34-S903D-W-M2

MLLA4-UNV1-1R-SRG1-M2

MLLA4-UNV1-S903D-WH-M2

MLLA4-UNV34-W-M2

MLLAN2NCS-UNV1-S903-1R-WH-M2

MLLAN2N-UNV1-S891-W-M2

MLLAN2N-UNV1-S903D-M2

MLLAN2N-UNV34-M2

MLLAN2N-UNV34-S903-M2

MLLAN2N-UNV34-S903-P-M2

MLLA4N-UNV34-W-M2

MLLAN2CS-UNV1-S903-M2

MLLAN2N-UNV34-S891-M2

MLLAN2-UNV1-S903D-M2

MLLAN2-UNV34-S903-P-M2

MLLAN4N-UNV1-W-M2

MLLAN4-UNV1-S891-P-M2

MLLAN4-UNV34-S903D-P-M2

MLLAW2N-UNV1-W-M2

MLLAW2-UNV1-S891-W-M2

MLLAW2-UNV34-S903-P-M2

MLLAW4-UNV1-S903D-M2

MLLAW4-UNV34-S903-M2

MLLA2N-UNV1-S891-P-M2

MLLA2-UNV1-S903-SRG1-EM1-M2

MLLA4NCW-UNV1-M2

MLLAN2N-UNV1-P-M2

MLLAN2N-UNV34-S903D-M2

MLLAN2-UNV1-S891-M2

MLLAN2-UNV1-S891-P-M2

MLLAN2-UNV1-S903-M2

MLLAN2-UNV34-M2

MLLAN2-UNV34-S903D-W-M2

MLLAN4N-UNV1-S891-M2

MLLAN4N-UNV1-S903-P-M2

MLLAN4N-UNV34-S891-M2

MLLAN4-UNV1-P-M2

MLLAN4-UNV1-S903D-M2

MLLAN4-UNV1-S903-P-M2

MLLAN4-UNV34-S891-W-M2

MLLAN4-UNV34-S903-P-M2

MLLAW2N-UNV1-P-M2

MLLAW2N-UNV1-S903-P-M2

MLLAW2N-UNV34-S891-M2

MLLAW2N-UNV34-S903D-P-M2

MLLAW2N-UNV34-W-M2

MLLAW2-UNV1-S891-M2

MLLAW2-UNV1-S903D-W-M2

MLLAW2-UNV34-M2

MLLAW2-UNV34-S903D-M2

MLLAW2-UNV34-S903D-W-M2

MLLAW4N-UNV1-P-M2

MLLAW4N-UNV1-S903D-P-M2

MLLAW4N-UNV1-W-M2

MLLAW4N-UNV34-P-M2

MLLAW4N-UNV34-S903D-M2

MLLAW4N-UNV34-S903-M2

MLLAW4-UNV1-S891-M2

MLLAW4-UNV1-S891-W-M2

MLLAW4-UNV1-S903-P-M2

MLLAW4-UNV1-W-M2

MLLAW4-UNV34-S891-W-M2

MLLAW4-UNV34-S903D-P-M2

M2-MLLA2-UNV1-DRIVER-KIT

MLLA2NCS-UNV1-S903-M2

MLLA2N-UNV34-S903-W-M2

MLLA2-UNV1-S903D-WH-M2

MLLA4NCS-UNV34-M2

MLLA4N-UNV34-S891-W-M2

MLLA4N-UNV34-S903D-P-M2

MLLA4-UNV34-S903D-W-M2

MLLA4-UNV34-S903-W-M2

MLLAN2N-UNV1-W-M2

MLLAN2N-UNV34-S891-W-M2

MLLAN2-UNV1-S903D-W-M2

MLLAN2-UNV34-S903D-P-M2

MLLAN2-UNV34-W-M2

MLLAN4N-UNV1-S903-M2

MLLAN4N-UNV34-P-M2

MLLAN4-UNV1-M2

MLLAN4-UNV34-S891-P-M2

MLLAN4-UNV34-S903-M2

MLLAW2N-UNV1-S903D-W-M2

MLLAW2N-UNV34-P-M2

MLLAW2-UNV1-P-M2

MLLAW2-UNV1-S903D-P-M2

MLLAW2-UNV34-S903D-P-M2

MLLAW2-UNV34-W-M2

MLLAW4N-UNV34-M2

MLLAW4N-UNV34-S891-W-M2

MLLAW4-UNV1-S891-P-M2

MLLAW4-UNV1-S903D-W-M2

MLLAW4-UNV34-S903D-M2

MLLA2N-UNV1-S903D-W-M2

MLLA2N-UNV1-W-M2

MLLA2N-UNV34-S891-W-M2

MLLA2N-UNV34-S903D-W-M2

MLLA2-UNV1-W-M2

MLLA2-UNV34-S891-W-M2

MLLA2-UNV34-S903-W-M2

MLLA2-UNV34-W-M2

MLLA4N-UNV1-S891-WH-M2

MLLA4N-UNV1-S903-WH-M2

MLLA4N-UNV1-WH-M2

MLLA4N-UNV34-S891-P-M2

MLLA4-UNV1-S891-WH-M2

MLLA4-UNV1-S903-WH-M2

MLLA4-UNV1-WH-M2

MLLA4-UNV34-S891-W-M2

MLLAN2N-UNV1-M2

MLLAN2N-UNV1-S891-P-M2

MLLAN2N-UNV1-S903D-P-M2

MLLAN2N-UNV1-S903-M2

MLLAN2N-UNV1-S903-P-M2

MLLAN2N-UNV34-S903D-W-M2

MLLAN2N-UNV34-S903-W-M2

MLLAN2-UNV1-M2

MLLAN2-UNV1-S903-W-M2

MLLAN2-UNV34-P-M2

MLLAN2-UNV34-S891-W-M2

MLLAN4N-UNV1-M2

MLLAN4N-UNV1-S891-P-M2

MLLAN2-UNV34-S891-P-M2

MLLAN4N-UNV1-S903D-M2

MLLAN4N-UNV34-S903-P-M2

MLLAN4-UNV34-M2

MLLAW2N-UNV1-S891-W-M2

MLLAW2N-UNV34-S903-P-M2

MLLAW2-UNV34-S891-P-M2

MLLAW4N-UNV1-S903-M2

MLLAW4N-UNV34-W-M2

MLLAW4-UNV34-S891-M2

MLLA4-UNV1-P-M2

MLLA4-UNV1-S903D-M2

MLLAN4N-UNV1-S903D-P-M2

MLLAN4N-UNV34-S903D-M2

MLLAN4N-UNV34-S903D-W-M2

MLLAN4N-UNV34-S903-W-M2

MLLAN4-UNV1-S903D-W-M2

MLLAN4-UNV1-S903-W-M2

MLLAN4-UNV34-P-M2

MLLAN4-UNV34-W-M2

MLLAW2N-UNV1-S891-M2

MLLAW2N-UNV1-S903D-M2

MLLAW2N-UNV34-S891-W-M2

MLLAW2N-UNV34-S903D-W-M2

MLLAW2N-UNV34-S903-W-M2

MLLAW2-UNV1-S903-W-M2

MLLAW2-UNV34-P-M2

MLLAW2-UNV34-S891-W-M2

MLLAW4N-UNV1-S891-W-M2

MLLAW4N-UNV1-S903-W-M2

MLLAW4N-UNV34-S903-P-M2

MLLAW4-UNV1-P-M2

MLLAW4-UNV34-M2

MLLAW4-UNV34-S891-P-M2

MLLAW4-UNV34-S903-W-M2

MLLA4-UNV1-SRG1-M2

MLLAN2N-UNV1-S903D-W-M2

MLLAN2N-UNV1-S903-W-M2

MLLAN2N-UNV34-W-M2

MLLAN2-UNV34-S891-M2

MLLAN4N-UNV1-S891-W-M2

MLLAN4N-UNV34-S903-M2

MLLAN4-UNV1-W-M2

MLLAW2N-UNV1-S891-P-M2

MLLAW2N-UNV34-S903-M2

MLLAW2-UNV34-S891-M2

MLLAW4N-UNV1-S903D-W-M2

MLLAW4N-UNV34-S903-W-M2

MLLAW4-UNV34-P-M2

MLLAW2N-UNV34-M2

MLLA2NCS-UNV1-S903D-P-M2

MLLAN2N-UNV34-S891-P-M2

MLLAN2-UNV1-S903D-P-M2

MLLAN2-UNV34-S903-W-M2

MLLAN4N-UNV34-M2

MLLAN4-UNV1-S891-W-M2

MLLAN4-UNV34-S903D-W-M2

MLLA2N-UNV1-M2

MLLA2-UNV34-S903-M2

MLLA2-UNV1-S891-M2

MLLA4N-UNV1-P-M2

MLLA4N-UNV34-S903-P-M2

MLLA2-UNV34-P-M2

MLLA4-UNV1-S903-P-M2

MLLA4-UNV34-S891-P-M2

MLLA2N-UNV34-M2

MLLA2-UNV34-S903-P-M2

MLLAW4N-UNV1-S891-M2

MLLA4-UNV34-M2

MLLA2N-UNV1-S891-M2

MLLA2N-UNV1-S903-M2

MLLA2N-UNV34-S903D-M2

MLLA2-UNV1-S903D-M2

MLLA4N-UNV1-S903D-P-M2

MLLA4N-UNV34-M2

MLLA4-UNV34-S903D-M2

MLLAW2-UNV1-S903-M2

MLLA2-UNV1-S903-P-M2

MLLA4N-UNV34-S903-M2

MLLA-EM1-M2-KIT

M2-MLLA-SRG1-KIT

M2-MLLA-SRG3-KIT

MLLA2-UNV1-S903-EM1-M2

MLLA4-UNV1-S903-EM1-M2

MLLA2P15-UNV1-S903-M2

MLLA2P12-UNV1-S903-M2

MLLA2-UNV1-S903D-EM1-M2

MLLA4P12-UNV1-M2

MLLA2P20-UNV1-S903-M2

MLLA4CW-UNV1-S903D-EM1-M2

MLLA2CS-UNV1-S903-M2

MLLA4CS-UNV1-S903-EM1-M2

MLLA4P15-UNV1-S903-M2

MLLA4CW-UNV1-S903-EM1-M2

MLLA2CW-UNV1-S903D-EM1-M2

MLLA4CS-UNV1-M2

MLLA4P12-UNV1-S903-M2

MLLA2CS-UNV1-S903-EM1-M2

MLLA2P15-UNV1-M2

MLLA4CW-UNV1-S903-M2

MLLA4-UNV1-S891-EM1-M2

MLLA2-UNV1-EM1-P-M2

MLLA4CS-UNV1-S903-SRG1-M2

MLLAN2CS-UNV1-M2

MLLAW4-UNV1-S903-SRG1-EM1-P-M2

MLLA2-UNV1-EM1-M2

MLLA4CS-UNV1-S903D-M2

MLLA4CS-UNV1-S903D-SRG1-M2

MLLA4N-UNV1-S903-EM1-WH-M2

MLLA4-UNV1-S903D-EM1-P-M2

MLLA2CS-UNV1-S891-SRG1-M2

MLLA2-UNV1-S891-EM1-M2

MLLA4CS-UNV1-SRG1-M2

MLLA4-UNV1-EM1-P-M2

MLLAN4CS-UNV1-SRG1-M2

MLLA4CS-UNV1-S891-SRG1-M2

MLLA4-UNV1-EM1-M2

MLLAN4-UNV1-S903D-EM1-M2

MLLAN2-P15-UNV1-S903D-P-M2

MLLA4P15-UNV1-M2

MLLA2-UNV1-S903-EM1-P-M2

MLLA4-UNV1-S903-EM1-P-M2

MLLA2CS-UNV1-M2

MLLA2CW-UNV1-S903-EM1-M2

MLLA4-UNV1-S903D-EM1-M2

MLLA2CW-UNV1-S903-M2

MLLA4P20-UNV1-S903-M2

MLLA4CW-UNV1-M2

MLLA4CS-UNV1-S903D-EM1-M2

MLLA2P12-UNV1-M2

MLLA2P20-UNV1-M2

MLLA2CS-UNV1-S903D-EM1-M2

MLLA2CW-UNV1-M2

MLLA4P20-UNV1-M2

MLLA4CS-UNV1-S903-M2
